MTU is the core brand of Rolls-Royce Power Systems AG, which is a world-leading provider of high- and medium-speed diesel and gas engines, complete drive systems, distributed energy systems and fuel injection systems for the most demanding requirements. Especially within the shipping sector the company has established a long and successful partnership with tens of thousands of engines in operation around the globe on all seas. q
Adopt original imported Perkins engine with mature, covering full power range from 100kVA up to 2000kVA. The engine features excellent combustion efficiency, low fuel consumption, strong load adaptability
Integrated container structure, dustproof and rainproof, low noise, original Perkins engine, low fuel consumption, stable power supply, all-round safety protection, convenient transportation, easy maintenance.
Product Images
Detail Information
Factory Strength
Haichai Power Technology (Jiangsu) Co., Ltd. was established in 2015, backed by 10 years of comprehensive experience in the production, manufacturing, and sales of power generators.
Our factory covers an area of over 12,000 square meters, with an annual production capacity of more than 3,000 generator sets. We are equipped with 10 sets of production equipment, 5 dedicated production lines, and a team of over 200 skilled employees.
FAQ
Q: Can the equipment be installed under hot weather?
A: We provide one-stop power generation solution, if you need to install and use it in hot weather, we will provide oil suitable for high temperature environment, and regularly check the battery level, replenish the distilled water, and regularly clean the dust and dirt on the heat sink of the generator set in order to improve the heat dissipation efficiency.
A: We provide one-stop power generation solutions, if you need to install and use in cold weather, you need the unit supporting the water jacket heater and other accessories.
A: If you need to buy accessories separately, you can contact hicpower@hicpower.com and explain the intention, we will have a commissioner to interface with you!
A: HiC Power Participates in Electricity-Related Exhibitions Across the Country.
| Cummins DCEC Specifications 50HZ | |||||||
| Genset Model | Standby Power | Prime power | Engine model | Dimension (L×W×H) (mm) | Weight (kg) | ||
| kVA | kW | kVA | kW | ||||
| HC-20GF | 28 | 22 | 25 | 20 | 4B3.9-G2 | 1660×750×1200 | 800 |
| HC-24GF | 33 | 26 | 30 | 24 | 4B3.9-G2 | 1660×750×1200 | 800 |
| HC-32GF | 44 | 35 | 40 | 32 | 4BT3.9-G2 | 1660×750×1200 | 810 |
| HC-44GF | 69 | 55 | 60 | 48 | 4BTA3.9-G2 | 1860×750×1200 | 850 |
| HC-64GF | 88 | 70 | 80 | 64 | 4BTA3.9-G11 | 2160×800×1300 | 1040 |
| HC-75GF | 110 | 88 | 100 | 80 | 6BT5.9-G2 | 2160×800×1300 | 1056 |
| HC-100GF | 125 | 100 | 115 | 92 | 6BTA5.9-G2 | 2160×800×1300 | 1096 |
| HC-120GF | 165 | 132 | 150 | 120 | 6BTAA5.9-G12 | 2300×850×1300 | 1400 |
| HC-150GF | 206 | 165 | 187.5 | 150 | 6CTA8.3-G2 | 2400×860×1380 | 1440 |
| HC-180GF | 248 | 198 | 225 | 180 | 6CTAA8.3-G2 | 2500×960×1450 | 1700 |
| HC-200GF | 275 | 220 | 250 | 200 | 6LTAA8.9-G2 | 2640×970×1450 | 2000 |
| HC-C220GF | 300 | 242 | 275 | 220 | 6LTAA8.9-G3 | 2600*1070*1500 | 2050 |
| HC-C320GF | 445 | 352 | 400 | 320 | 6ZTAA13-G3 | 2900*1200*1750 | 3000 |
| HC-C400GF | 555 | 440 | 500 | 400 | 6ZTAA13-G4 | 2900*1200*1750 | 3060 |
| HC-C400GF | 555 | 440 | 500 | 400 | QSZ13-G2 | 3150*1350*1800 | 3200 |
| HC-C450GF | 625 | 495 | 562.5 | 450 | QSZ13-G3 | 3150*1350*1800 | 3250 |
| CCEC Cummins SERIES 50HZ | |||||||
| Genset Model | Standby Power | Prime power | Engine model | Dimension(L×W×H) (mm) | Weight(kg) | ||
| kVA | KW | kVA | KW | ||||
| HC-250GF | 345 | 275 | 312.5 | 250 | MTAA11-G3 | 3150×1050×1700 | 2450 |
| HC-275GF | 380 | 303 | 345 | 275 | NTA855-G2A | 3100×1000×1700 | 2600 |
| HC-320GF | 440 | 352 | 400 | 320 | QSNT-G3 | 3400×1280×1800 | 3050 |
| HC-360GF | 495 | 396 | 450 | 360 | KTA19-G3 | 3300×1350×2000 | 3600 |
| HC-400GF | 550 | 440 | 500 | 400 | KTA19-G3A | 3420×1250×1930 | 3720 |
| HC-480GF | 660 | 528 | 600 | 480 | KTA19-G8 | 3550×1550×2100 | 4000 |
| HC-500GF | 688 | 550 | 625 | 500 | KTAA19-G6A | 3550×1550×2100 | 4400 |
| HC-600GF | 798 | 660 | 725 | 600 | KTA38-G2 | 4260×1650×2350 | 6350 |
| HC-640GF | 880 | 704 | 800 | 640 | KTA38-G2B | 4260×1650×2350 | 6350 |
| HC-720GF | 990 | 792 | 900 | 720 | KTA38-G2A | 4350×1650×2350 | 6650 |
| HC-800GF | 1100 | 880 | 1000 | 800 | KTA38-G5 | 4500×1850×2350 | 6900 |
| HC-900GF | 1238 | 990 | 1125 | 900 | KTA38-G9 | 4500×2100×2500 | 7500 |
| HC-1000GF | 1375 | 1100 | 1250 | 1000 | KTA50-G3 | 5100×2280×2500 | 9600 |
| HC-1200GF | 1650 | 1320 | 1500 | 1200 | KTA50-GS8 | 5100×2280×2500 | 13000 |
| Cummins DCEC Specifications 60HZ | |||||||
| Genset Model | Standby Power | Prime power | Engine model | Dimension (L×W×H) (mm) | Weight (kg) | ||
| kVA | kW | kVA | kW | ||||
| HC-20GF | 28 | 22 | 25 | 20 | 4B3.9-G2 | 1660×750×1200 | 800 |
| HC-24GF | 33 | 26 | 30 | 24 | 4B3.9-G2 | 1660×750×1200 | 800 |
| HC-32GF | 44 | 35 | 40 | 32 | 4BT3.9-G2 | 1660×750×1200 | 810 |
| HC-44GF | 69 | 55 | 60 | 48 | 4BTA3.9-G2 | 1860×750×1200 | 850 |
| HC-64GF | 88 | 70 | 80 | 64 | 4BTA3.9-G11 | 2160×800×1300 | 1040 |
| HC-75GF | 110 | 88 | 100 | 80 | 6BT5.9-G2 | 2160×800×1300 | 1056 |
| HC-100GF | 125 | 100 | 115 | 92 | 6BTA5.9-G2 | 2160×800×1300 | 1096 |
| HC-120GF | 165 | 132 | 150 | 120 | 6BTAA5.9-G12 | 2300×850×1300 | 1400 |
| HC-150GF | 206 | 165 | 187.5 | 150 | 6CTA8.3-G2 | 2400×860×1380 | 1440 |
| HC-180GF | 248 | 198 | 225 | 180 | 6CTAA8.3-G2 | 2500×960×1450 | 1700 |
| HC-200GF | 275 | 220 | 250 | 200 | 6LTAA8.9-G2 | 2640×970×1450 | 2000 |
| HC-C220GF | 300 | 242 | 275 | 220 | 6LTAA8.9-G3 | 2600*1070*1500 | 2050 |
| HC-C320GF | 445 | 352 | 400 | 320 | 6ZTAA13-G3 | 2900*1200*1750 | 3000 |
| HC-C400GF | 555 | 440 | 500 | 400 | 6ZTAA13-G4 | 2900*1200*1750 | 3060 |
| HC-C400GF | 555 | 440 | 500 | 400 | QSZ13-G2 | 3150*1350*1800 | 3200 |
| HC-C450GF | 625 | 495 | 562.5 | 450 | QSZ13-G3 | 3150*1350*1800 | 3250 |
| CCEC CUMMINS SERIES 60HZ | |||||||
| Genset Model | Standby Power | Prime power | Engine model | Dimension(L×W×H) (mm) | Weight(kg) | ||
| kVA | KW | kVA | KW | ||||
| HC-200GF | 275 | 220 | 250 | 200 | NT855-GA | 2980×1000×1700 | 2320 |
| HC-250GF | 345 | 275 | 312.5 | 250 | NTA855-G1 | 3150×1050×1700 | 2450 |
| HC-275GF | 380 | 303 | 345 | 275 | NTA855-G1B | 3100×1000×1700 | 2600 |
| HC-315GF | 438 | 350 | 394 | 315 | QSNT-G3 | 3400×1280×1800 | 3050 |
| HC-360GF | 495 | 396 | 450 | 360 | KTA19-G2 | 3300×1350×2000 | 3600 |
| HC-400GF | 550 | 440 | 500 | 400 | KTA19-G3 | 3420×1250×1930 | 3720 |
| HC-480GF | 660 | 528 | 600 | 480 | KTAA19-G5 | 3550×1550×2100 | 4000 |
| HC-500GF | 688 | 550 | 625 | 500 | KTAA19-G6A | 3550×1550×2100 | 4400 |
| HC-600GF | 798 | 660 | 725 | 600 | KT38-G | 4260×1650×2350 | 6350 |
| HC-700GF | 963 | 770 | 875 | 700 | KTA38-G1 | 4260×1650×2350 | 6350 |
| HC-720GF | 990 | 792 | 900 | 720 | KTA38-G2 | 4350×1650×2350 | 6650 |
| HC-800GF | 1100 | 880 | 1000 | 800 | KTA38-G2A | 4500×1850×2350 | 6900 |
| HC-900GF | 1238 | 990 | 1125 | 900 | KTA38-G4 | 4500×2100×2500 | 7500 |
| HC-1000GF | 1375 | 1100 | 1250 | 1000 | KTA50-G3 | 5100×2280×2500 | 9600 |
| HC-1200GF | 1650 | 1320 | 1500 | 1200 | KTA50-G9 | 5100×2280×2500 | 13000 |
